Leda MAX™

Heavy Duty Wall & Column
Formwork System

LEDA MAX™ is a heavy-duty modular steel wall and column formwork system designed for high-performance concrete construction. It delivers strength, durability, and efficiency across a wide range of structural and civil engineering projects

Key Features

  • Concrete pressure capacity up to 80 kN/m²
  • Heavy-duty steel frame construction
  • Available in HDG (Hot Dip Galvanised or Powder Coated finish
  • 18mm high-grade birch plywood for long-lasting performance
  • Fast assembly and striking
  • Modular system for maximum flexibility

Leda MAX™

Extended Panel Size Range

LEDA MAX™ panels are available in a wide range of sizes, offering greater flexibility compared
to standard systems.This reduces infill requirements and increases efficiency on site.

Panel Heights Available:

3300 mm, 3000 mm, 2700 mm, 2400 mm, 1200 mm, 600 mm
Panel Widths Available:
2400 mm, 1800 mm, 1500 mm, 1200 mm, 1000 mm, 900 mm, 750 mm, 720 mm, 600 mm, 450
mm, 300 mm
Panels available from 300 mm width upwards allow precise wall forming with minimal infill.
improving productivity and reducing labour costs

All Ledamax
panels and factory

System Components

  • Wall panels
  • Column panels
  • Tie rods and wing nuts
  • Clamps and connectors
  • Corner panels
  • Alignment walers
  • Push-pull props
  • Working platforms

Applications

  • Residential construction
  • Commercial buildings
  • Basements and retaining walls
  • Civil engineering projects

Why LEDA MAX™

LEDA MAX™ provides a reliable, efficient, and cost-effective solution for modern construction. Its
Strength, flexibility, and proven performance make it an ideal choice for contractors.
